Sierra Shields Low Permeation Marine Fuel Hose 5/16" per Foot

Shields Marine 5/16" Type A1-15 Low Permeation Series 368 Fuel Hose 100# Working Pressure.

SAE J1527 Type A1-15 - ISO 7840. Low permeation fuel hose has a plastic barrier veneer with NBR outer layer tube to limit permeation.

Polyester reinforced and complies with EPA and CARB low permeation requirements. Weather/UV resistant NBR/PVC cover.

Fuel Feed - gasoline up to 85% ethanol blended fuels / diesel / biodiesel all blends.

Meets USCG Type A1-15 requirements for pleasure boats.
ISO 7840 Type A1.
NMMA/CE type accepted.
Temperature range: -20°F to 212°F.

Sierra 16-368-0566 Shields Low Permeation Marine Fuel Hose 5/16" By The Foot

Sierra Shields Low Permeation Marine Fuel Hose has a plastic barrier veneer with an NBR outer layer tube to prevent permeation. This polyester reinforced hose complies with EPA and CARB very low permeation requirements and is weather/UV resistant. This hose is primarily used for fuel feed (gasoline up to 85% ethanol blended fuels/diesel/all bio-diesel blends).

Features:

• Meets USCG Type A1-15 requirements for pleasure boats
• Meets SAEJ1527 Type A1-15, ISO 7840 Type A1, and NMMA/CE type accepted standards
• Temperature Range: -20°F to 212°F
• Sold by the foot

Specifications:

• O.D.: 5/8" or 15.49mm
• I.D.: 5/16" or 7.9mm
• Wt. "C": 13
• Max WP: 100
